The SmalTec GM703 Micro-EDM Nano Grinding
Another example of SmalTec innovation, the GM703 was developed with high precision 3-dimensional nano-motion. The GM703 is the next-generation Micro EDM with Nano Grinding technology.
Specifications Download the GM703 Specifications (.pdf)
2” x 2” Work Area with 10nm Movement Automatic Part Detection and Location
Full Interpolation of all Three Axis Tool Rotation up to 6,000 RPM Selectable
G-Code Equipped
*All specifications subject to change

GM703 Future
SmalTec is continuously advancing the technology based on the challenges customers present to us. The following list is a sampling:
Auto Tool Wear Compensation
Tool rotation using Servo for Precise Positioning Control
Tool Change Over (automated)
Vision System for Specialized Alignment Application
Automated Workpiece Exchange
C-Rotation for Work Piece
